Product Description
Array Radar low altitude radar surveillance system is a set of three-dimensional space surveillance radar for low altitude small targets, Omni-directional, high elevation coverage. It is mainly responsible for real-time reconnaissance of birds, aircraft, ground personnel, vehicles and other targets in the surrounding area, discovering and tracking targets, and outputting or reporting target information to designated users. Radar supports three kinds of erection modes: fixed mode, vehicle mode and portable mode. It is flexible for different application scenarios.
Product characteristics:
1) All-Space Three-coordinate Detection
All-day, all-weather and large-scale regional reconnaissance and surveillance can effectively acquire the azimuth, distance and altitude (pitch angle) three-dimensional position information of surrounding aircraft and birds, which has the characteristics of long detection distance and high data rate.
2) Target tracking and guidance
The radar can not only realize the search and detection of the surrounding targets, but also report the information of the detected targets. It can also guide high-precision angular measurement equipment according to the user's choice of high-speed tracking target. 64 targets can be tracked at the same time, and the position coordinates of the targets can be updated regularly.
3) Strong recognition ability
Radar uses automatic target classification and recognition. It can detect and recognize small targets at low altitude (personnel, vehicles, small UAV, helicopters, birds), and the recognition probability is more than 80%.
4) Strong adaptability
It can meet the needs of target detection in plateau, mountain, hilly and other complex environments. At the same time, the target information can be real-time output to the operator, or through communication equipment, reported to other equipment to complete the target information guidance.
Specifications Radar detection:
· Isolating Signal Bandwidth:
| Indicators | Parameters |
| Working Frequency: |
Ku band |
| Working Mode: |
Pulse Doppler |
| Detection Range : |
>=5km |
| Antenna Fan Sweep Range : | 0-360° |
| -Pitch Beam Width : | 10-40° |
| -Azimuth Beam Width: | 2.4° |
| Target Radia Velocity: | 2.8=144km/h |
| RCS | = 0.01M ² |
| Working Mode: | Pulse Doppler |
| Min Detection Range: | <=120m |
| Ranging Accuracy: | <10m |
| Azimuth Accuracy: | <=0.5° |
| Distance Resolution: | <=15m |
| Azimuth Resolution: | <=0.5° |
| Speed accuracy: | 0.293m/s |
| Transmit Power: | 120W |
| Weight: | 55K |
Applicable for Radar detection:
Prisons or other large sensitive locations such as or governmental compounds. Homeland Security, Correctional Centers,Petrochemical Industry, Sports Venues and Theaters, VIP Convoy Protection, Bomb Prevention/Disposal, Schools and Universities Government and , Power Generating Plants...etc.
FAQ
1. Why choose us?
* Passionate, experienced and highly-educated R & D and sales team;
* Reasonable price and reliable products, skillful and careful assembly;
* Strict quality assurance and quick aftersales service;
* Lifetime technical support, can come with customized setting.
2.Are you manufacturer or trading company?
*We are manufacturer with 15 years of experience.Welcome to visit our factory.
3.Can we use our logo on the products?
* Yes, they are. As a professional all Signal Jammer manufacturer, we offer OEM and ODM service.
4. How about your product warranty?
* We offer one-year warranty upon delivery.
Terms and conditions:
| Delivery Time Schedule | Delivery time is 2-3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 50% advance, 50% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
