5.8G 4G RCIED backpack Drone Signal Jammer For military with big battery
| Frequency Range | 20-6000MHz/700-2600MHz |
| Frequency: | CDMA/GSM/3G Cellphone |
| Jammer Type | Portable Jammer |
| Channel Number | 5 |
| Each Bands Power | 40W |
| Total Output Power | 200W |
| Jamming Range | 2-90m |
| Application | Military Units, Prison, Police, Bomb Disposal |
Description:
This is a portable type signal shielding device .It is easy to carry, flexible to use, also with optional built-in high capacity battery ,
Detonation and confidence leaking, threaten from Road-side Remote Improvised Explosive Device (RCIED) have been a serious risk for the lives' safety of the bomb disposal troop and law enforcement quality of anti-terrorism unit. To ensure the smooth process of law enforcement task and keep people’s lives safety, have been the tremendous challenge and task in many parts of the world.
These are the reasons that this model of jammer is so important!
so it especially suitable for application in: large venue, infantry troop and military security force, the SWAT team, counter-terrorism unit, the drug control unit, explosion-proof, EOD team, checkpoint, the hostage negotiation, and border control, etc.
Functional characteristics:
- frequencies can be customized by customers.So we also can choose the frequencies for blocking deones as 2400-2500MHZ and 5.8G.
- it can with multiple power supplies :if with built-in battery, it can provide power for the jammer working about 2 hours. Also it can be powered by 220V AC or an on-board power supply.
- this jammer can be customized as 3 or 4 0r 5 or 6 or 8 bands ,and each band could be 10 watts or 15 watts as customer's request.
- The operator can carry it forward through the hills and muddy road, as well as Climbing steep mounts and stairs avoid casualties and improve the combat efficiency.
- Efficient cooling heat disipation system,including high performance aluminum alloy heat sink and several wind fans,so th e jammer can non-stop work fo long time.
Specifications:
|
Output interface |
Shield band of frequency |
RF output power |
Output power/channel |
|
CH1 |
851-894 MHz |
15w |
17 dBm/30KHz(min) |
|
CH2 |
1805-1880 MHz |
15w |
14 dBm/30KHz(min) |
|
CH3 |
2110-2170 MHz |
15w |
15.5 dBm/30KHz(min) |
|
CH4 |
2100-2170 MHZ |
15w |
15.5 dBm/30KHz(min) |
|
CH5 |
925-960 MHz |
15w |
17.5 dBm/30KHz(min) |
|
Power supply: AC110-220V Shielding area: 30-500M @ according to signal density of mobile network |
|||
|
Power consumption: 200W Weight:12Kg Size(length × wind × high):390×390×240mm |
|||
|
Humidity: 30%-95% Running Temperature: -20 to +55 Celsius Degree |
|||
Competitive Advantage:
- Easy of mobility, can carry it as a backpack.the toal weight of this is about 12KG.
- the color could be customised as black or green for military and army.
- with good quantity LI-battery ,can no-stop work for 2 hours.
- High Power RF amplifiers with VSWR and temperature self-protection technology.
- with good cooling system, can operate for long time.
- Using digital interference technology, overall effective suppression of target spectrum
- independent module design. Each module can separate switch,disassemble. So it is convenient for maintenance and update.
- Perfect Alarm System, fully protected circuit in case of disconnection of antennas.
Applications:
large venue, infantry troop and military security force, the SWAT team, counter-terrorism unit, the drug control unit, explosion-proof, EOD team, checkpoint, the hostage negotiation, and border control, etc.
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
