VHF /UHF/ GSM /WIFI/ LTE /4G radio frequency jammer with 14 antennas for polices
Description:
This full spectrum signal jammer is with 14 channels. RF output power of each channel is no less than 1 watt, effective shielding any cheating signal.And one important thing is :the antenna is hidden inside,cut all the signals but not easy be found where the jammer is.
The jammer adopts DC 19 power supply. It is equipped with a precision voltage regulator circuit, even if the voltage fluctuation is changeable, it also won't affect the normal work .
Host cooling structure of shell is by professional design. It can endure high temperature environment, by transferring heat quickly to the heat exchange surface , avoid heat local accumulation.
Two mute fans instant remove the power amplifier heat, to ensure the stability of the host long continuous operation.
it is suitable for use in school examination rooms, prisons, clubhouses and government departments.
epartments.
Specifications:
|
Output port |
Frequency |
Average out- |
Channel out- |
|
150MHZ |
135-200 MHz |
30dBm |
6dBm/30KHz(min) |
|
250MHZ |
200-300 MHz |
30dBm |
1dBm/30KHz(min) |
|
350MHZ |
300-400 MHz |
30dBm |
1dBm/30KHz(min) |
|
450MHZ |
400-500 MHz |
29dBm |
-2dBm/30KHz(min) |
|
550MHZ |
500-600 MHz |
29dBm |
-3dBm/30KHz(min) |
|
650MHZ |
600-700 MHz |
29dBm |
3dBm/30KHz(min) |
|
750MHZ |
700-800 MHz |
29dBm |
-2dBm/30KHz(min) |
| CDMA |
851-894 MHZ |
30dBm | 3dBm/30KHz(min) |
| GSM | 925-960 MHZ | 30dBm | 3dBm/30KHz(min) |
| DCS | 1805-1990 MHZ | 30dBm | 3dBm/30KHz(min) |
| 3G | 2110-2170 MHZ | 30dBm | 3dBm/30KHz(min) |
| WIMAX | 2300-2400 MHZ | 30dBm | 3dBm/30KHz(min) |
| WIFI | 2400-2500 MHZ | 30dBm | 3dBm/30KHz(min) |
| 4G | 2620-2690 MHZ | 30dBm | 3dBm/30KHz(min) |
|
Power supply: AC adapter (AC220V-DC19V) Weight :3.5kg |
|||
|
Working Hours:Continuously more than 24hours Power consumption :80watts |
|||
|
Humidity: 30%-95% Running Temperature: -20 to +55 Celsius Degree |
|||
Competitive Advantage:
Design of soft-start circuit, this function can maintain the stable operation condition, avoid mechanical switch to produce lighter phenomenon.
with good cooling system, can operate for long time.
It is a high-tech product made by our company .it adopts foreign advanced technologyand imported components to ensure the quantity and stability.
Effectively making subsections of frequency spectrums, just interfering downlink and causing no interception of base station
Perfect Alarm System, fully protected circuit in case of disconnection of antennas.
this jammer is with 14 bands ,can block all mobile signal and radio signal .
the antenna could be designed inside or expose to the air!
Applications:
1. Conference room, auditoriums, law court, library, exam room, school, cinema, theater, museum, hospital etc.
2. Places where using mobile phones is prohibited such as Service Station, Security Services, Militaries Units, Border Patrol and Drug Enforcement, Customs, etc.
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
R&D Group in USA
We have strong and excellent R&D group in USA, who dedicated to the research and development of our new products.We are consumer-oriented and do our best to offer satisfying products to customers.
Manufacturer in CHINA
A full line of products - We have a full line of cellular jamming products from low-cost portable units to high-spec industrial units.
We are the specialists in cell phone Jammers and GPS Jammer, WIFI Jammer, 3G Jammer, 4G Jammer, Lojack Jammer, UHF/VHF Jammer, RF Jammer, Audio Jammer,Wireless Video Jammer and signal Repeater/Amplifier/Booster etc.We offer unparalleled professional service and advice for our personal and commercial products. 10+ years of industry experience makes us the specialists you can trust. We pioneered all kind of jammers online sales, and offer the best cellular jamming prices worldwide - guaranteed. We are a developer, manufacturer and reseller of cell phone jamming devices and signal Repeater devices. products include GSM Jammer, CDMA jammer, DCS/PCS Jammer, GPS Jammer, WIFI Jammer, 3G Jammer, Audio Jammer, Wireless Video Jammer, Dual Band Repeater,Tri Band Repeater etc.
Our Jammer type have Portable Jammers, Desktop Jammer, Prison Jamme, Vehicular jammer, Bomb Jammer, IED Jammer and RF Jammer.
