Product Specifications:
|
Item |
Specification |
|---|---|
|
Channel Quantity |
16 bands (16 channels) |
|
Frequency Range |
20 MHz ~ 5875 MHz |
|
Input Power |
220–230VAC & DC24V |
|
RF Output Power |
100W per channel for standard bands; 50W for 5.8G band |
|
Mounting Type |
Vehicle-mounted mobile type, support fixed installation on vehicle |
|
Covered Signals |
UAV remote control / video transmission, cellular signals, WiFi, RF remote signals |
|
Target Market |
Pakistan (frequency tuning available according to local spectrum) |
|
Working Mode |
Independent channel control, individual on/off adjustable |
Frequency band used - Country Pakistan (customizable frequency band):
| Band | Frequency Range | RF Output Power |
|---|---|---|
| Band 1 | 20 MHz – 100 MHz | 100W |
| Band 2 | 136 MHz – 174 MHz | 100W |
| Band 3 | 315 MHz | 100W |
| Band 4 | 433 MHz | 100W |
| Band 5 | 750 MHz – 803 MHz | 100W |
| Band 6 | 869 MHz – 960 MHz | 100W |
| Band 7 | 1170 MHz – 1380 MHz | 100W |
| Band 8 | 1560 MHz – 1580 MHz | 100W |
| Band 9 | 1805 MHz – 1880 MHz | 100W |
| Band 10 | 2110 MHz – 2170 MHz | 100W |
| Band 11 | 2300 MHz – 2500 MHz | 100W |
| Band 12 | 2500 MHz – 2700 MHz | 100W |
| Band 13 | 3400 MHz – 3600 MHz | 100W |
| Band 14 | 3600 MHz – 3800 MHz | 100W |
| Band 15 | 5150 MHz – 5350 MHz | 100W |
| Band 16 | 5725 MHz – 5875 MHz | 50W |
Product shipping packaging size and weight:
|
Item |
Dimension |
Net Weight |
Gross Weight (with wooden case) |
|---|---|---|---|
|
Main Unit |
960mm × 690mm × 790mm |
76.55 kg |
103.65 kg |
|
Vehicle Top Enclosure |
1840mm × 910mm × 740mm |
29 kg |
49.60 kg |
|
Battery Wooden Case |
960mm × 680mm × 700mm |
100 kg |
131.7 kg |
Product Overview
This is a 16-band vehicle-mounted mobile RF security shielding device, covering frequency range from 20 MHz to 5875 MHz. It is developed for border security and low-altitude UAV risk control, optimized for Pakistan local spectrum. It can suppress UAV remote control & video link, cellular mobile signals, WiFi and general RF remote signals. Vehicle-mounted design enables rapid mobile deployment for patrol security missions.
Key Advantages
16 independent RF channels, wide frequency coverage 20–5875 MHz, handles multiple types of wireless RF signals
High power design: 100W per channel for normal bands, 50W for 5.8G channel, optimized power distribution for stable performance and long effective distance
Mobile vehicle installation, fast setup for mobile protection zone
Targets UAV control & FPV transmission, 2G/3G/4G/5G cellular, WiFi and common RF remote signals
Modular design with independent channel switches, flexible band selection to match Pakistan local spectrum
High-gain antenna kit, reinforced cooling system, stable long-hour operation for outdoor & border field conditions
Application
Border mobile security patrol, unauthorized UAV low-altitude prevention, mobile protection for key zones, field security duty. Suitable for Pakistan security & border protection projects.
Specifications
Band: 16 Channels
Frequency Range: 20 MHz ~ 5875 MHz
RF Output Power: 100W per channel (standard bands), 50W for 5.8G
Mounting: Vehicle-mounted mobile type
Covered Signals: UAV remote & video link, mobile cellular, WiFi, RF remote signals
Target Market: Pakistan (custom frequency tuning available)
Control: Individual channel on/off control
Applicable Area:
• Mainly used in examination rooms, prisons, gas stations, mobile phone bombs, oil depots, LPG stations,detention centers, interrogation rooms, courts,
• Reform-through-labour teams, conference rooms, movie theaters, churches, libraries, school dormitories;
• Special security and confidential occasions (confidential office, negotiation room, mobile vehicles, mobile political and business dignitaries guarding the scene;
• All kinds of military sites and other prohibited places to use mobile phones.
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
Important Notes for Jamming Distance: The jamming distances we mentioned on website are for customer's reference only. The actual jamming distance will be varied depending on the signal strength and the use location and if full charges, etc.
Important Notes for Portable Jammers with No Cooling Fan: Do not use the jammer when it is charging, or it will burn the jammer as it has no built-in fan. If because of this factor due to the broken of the jammer, the customer will lose the authority of free repairation .
R&D Group in USA
We have strong and excellent R&D group in USA, who dedicated to the research and development of our new products.We are consumer-oriented and do our best to offer satisfying products to customers.
Manufacturer in CHINA
A full line of products - We have a full line of cellular jamming products from low-cost portable units to high-spec industrial units.
We are the specialists in cell phone Jammers and GPS Jammer, WIFI Jammer, 3G Jammer, 4G Jammer, Lojack Jammer, UHF/VHF Jammer, RF Jammer, Audio Jammer,Wireless Video Jammer and signal Repeater/Amplifier/Booster etc.We offer unparalleled professional service and advice for our personal and commercial products. 10+ years of industry experience makes us the specialists you can trust. We pioneered all kind of jammers online sales, and offer the best cellular jamming prices worldwide - guaranteed. We are a developer, manufacturer and reseller of cell phone jamming devices and signal Repeater devices. products include GSM Jammer, CDMA jammer, DCS/PCS Jammer, GPS Jammer, WIFI Jammer, 3G Jammer, Audio Jammer, Wireless Video Jammer, Dual Band Repeater,Tri Band Repeater etc.
Our Jammer type have Portable Jammers, Desktop Jammer, Prison Jamme, Vehicular jammer, Bomb Jammer, IED Jammer and RF Jammer.
After-sales & Customization
OEM & ODM band customization available, adjust frequencies according to Pakistan local radio spectrum. Full set including host, antennas and cables, with technical commissioning support. Buyer shall hold valid local authorization and comply with Pakistan radio regulatory laws.
