Mobile Phone Portable Signal Jammer Multi - Band Walky - Talky Output Power Selectable
| Frequency Range | 20-6000MHz/700-2600MHz |
| Frequency: | CDMA/GSM/3G Cellphone |
| Jammer Type | Portable Jammer |
| Channel Number | 14 |
| Each Bands Power | 50W |
| Total Output Power | 700W |
| Jamming Range | 2-90m |
| Application | Military Units, Prison, Police, Bomb Disposal |
Product Description:
Application
- VIP convoy protection
- Military camp
- Government building
- Police Checkpoints
- Bomb disposal and vehicle mounting for military complexe.
Specifications
Affected Frequency Ranges:
| Output Interface | Output Frequency | RF Output watt |
| CH1 | CDMA850:850-894MHz | 50W |
| CH2 | GSM900:925-960Mhz | 50W |
| CH3 | 1805-1880 Cellular HGSM1800/DCS | 50W |
| CH4 | PCS1900:1920-1990MHz | 50W |
| CH5 | 3G:2110MHz-2170MHz | 50W |
| CH6 | 2300/2400(US) / 2570-2690(EU) 4G WIMAX | 50W |
| CH7 | 1520-1580 GPS & Satellite; Odyssey; Globa* Star | 50W |
| CH8 | WiFi:2400-2500MHz | 50W |
| CH9 | 135-175 Walky-talky (VHF) | 50W |
| CH10 | 300-350 Walky-talky (UHF300) | 50W |
| CH11 | 400-480 Walky-talky (UHF400) | 50W |
| CH12 | 850-925 Walky-Talky (UHF800/900),TETRA,CDMA800 50w | 50W |
| CH13 | 1520-1580 GPS 50W (Option) | 50W |
| CH14 | 5700-5800MHz 20w WIFI 5.8G(Option) | 50W |
| Total output power : | 600Watt | |
| Power supply | 230VAC/~110VA | |
| Shielding area: | 500m @Depends on the signal strength at the application place. | |
| Total System Weight: | up to 38KG | |
| Cooling System | systematic Smart Cooling System | |
| Power Adjustment: | Multi level potentiometer | |
| Remote control | Full System Operation Control | |
| Antenna Type | External High Gain Omnidirectional Antennas | |
| Size(without antenna) | 56*45.5*26.5MM | |
| Battery Working time: | 1hours | |
| Power Consumption: | Max: 1200W | |
| Humidity: | Up to 80% | |
Accessories
- High Power Jammer
- Antenna
| Can be installed in the car, five bands, use pelican case, portable, inside battery. Designed for military use, high quality |
Have you ever considered that the high power signal jammer that designed with more than 200W high output can also be powered by the inside battery as well?
Just here this Portable Pelican Case RF Bomb Cellphone Signal Jammer GPS WiFi Blocker that you are viewing here owns such kind of function.
This is a RF bomb cellphone GPS WiFi signal blocker which can be widely used in places and conditions such as the VIP convoy protection, Military camp, Government building, Police Checkpoints, Bomb disposal and vehicle mounting for military complex and so many other places since this handheld pelican case cellphone GPS Bluetooth jammer owns excellent features as follows.
Firstly, each module of this RF bomb cellphone GPS WiFi signal blocker is controlled separately. Besides this cellphone GPS WiFi signal jammer is covered with Pelican case1560, portable, shockproof and also the inside battery, so that it owns light-weight and easy to carry.
Beside high quality cooling system has been applied on this handheld pelican case cellphone GPS Bluetooth jammer so that it can easily reach the goal of nonstop 24/7 working.
And since this handheld pelican case cellphone GPS Bluetooth jammer owns more than 200W output power so that the jamming distance of it is up to 200 meters depending on the signals strength to cut off the signals of CDMA, GSM, DCS, PCS, 3G, WiFi and also GPS as well. For more detail specifications of this RF bomb cellphone GPS WiFi signal blocker, just come here and see the following content.
Separate switch for each band, accompanied with a working LED Light.
Simple battery replacement.
Inside cooling fans and heat sink design ensure the device to work continuously. The device surface temperature does not exceed 40 °C after long time working
