30dBm Radio Frequency Hidden Signal Jammer RF Frequency Jammer
| Frequency Range | 20-6000MHz/700-2600MHz |
| Frequency: | CDMA/GSM/3G Cellphone |
| Jammer Type | Desktop Indoor Jammer |
| Channel Number | 8 |
| Each Bands Power | 3W |
| Total Output Power | 24W |
| Jamming Range | 2-30m |
| Application |
Military Units, Prison, Police, Bomb Disposal |
14 bands radio frequency jammer with fans, VHF /UHF/ GSM /WIFI/ LTE /4G jammer
Description:
This full spectrum signal jammer is with 14 channels. RF output power of each channel is no less than 1 watt, effective shielding any cheating signal.And one important thing is :the antenna is hidden inside,cut all the signals but not easy be found where the jammer is.
The jammer adopts DC 19 power supply. It is equipped with a precision voltage regulator circuit, even if the voltage fluctuation is changeable, it also won't affect the normal work .
Host cooling structure of shell is by professional design. It can endure high temperature environment, by transferring heat quickly to the heat exchange surface , avoid heat local accumulation.
Two mute fans instant remove the power amplifier heat, to ensure the stability of the host long continuous operation.
it is suitable for use in school examination rooms, prisons, clubhouses and government departments.
epartments.
Specifications:
|
Output port |
Frequency |
Average out- putting power |
Channel out- putting power |
|
150MHZ |
135-200 MHz |
30dBm |
6dBm/30KHz(min) |
|
250MHZ |
200-300 MHz |
30dBm |
1dBm/30KHz(min) |
|
350MHZ |
300-400 MHz |
30dBm |
1dBm/30KHz(min) |
|
450MHZ |
400-500 MHz |
29dBm |
-2dBm/30KHz(min) |
|
550MHZ |
500-600 MHz |
29dBm |
-3dBm/30KHz(min) |
|
650MHZ |
600-700 MHz |
29dBm |
3dBm/30KHz(min) |
|
750MHZ |
700-800 MHz |
29dBm |
-2dBm/30KHz(min) |
| CDMA |
851-894 MHZ |
30dBm | 3dBm/30KHz(min) |
| GSM | 925-960 MHZ | 30dBm | 3dBm/30KHz(min) |
| DCS | 1805-1990 MHZ | 30dBm | 3dBm/30KHz(min) |
| 3G | 2110-2170 MHZ | 30dBm | 3dBm/30KHz(min) |
| WIMAX | 2300-2400 MHZ | 30dBm | 3dBm/30KHz(min) |
| WIFI | 2400-2500 MHZ | 30dBm | 3dBm/30KHz(min) |
| 4G | 2620-2690 MHZ | 30dBm | 3dBm/30KHz(min) |
|
Power supply: AC adapter (AC220V-DC19V) Weight :3.5kg Semidiameter of interception:2m-50m(depend on site signal strength and environment condition) |
|||
|
Working Hours:Continuously more than 24hours Power consumption :80watts |
|||
|
Humidity: 30%-95% Running Temperature: -20 to +55 Celsius Degree |
|||
Competitive Advantage:
- Design of soft-start circuit, this function can maintain the stable operation condition, avoid mechanical switch to produce lighter phenomenon.
- with good cooling system, can operate for long time.
- It is a high-tech product made by our company .it adopts foreign advanced technologyand imported components to ensure the quantity and stability.
- Effectively making subsections of frequency spectrums, just interfering downlink and causing no interception of base station
- Perfect Alarm System, fully protected circuit in case of disconnection of antennas.
-
this jammer is with 14 bands ,can block all mobile signal and radio signal .
-
the antenna could be designed inside or expose to the air!
Applications:
1. Conference room, auditoriums, law court, library, exam room, school, cinema, theater, museum, hospital etc.
2. Places where using mobile phones is prohibited such as Service Station, Security Services, Military Units, Border Patrol and Drug Enforcement, Customs, etc.
Monitor software function: (Option)
· Remote control switches of each machine.
· Remote viewing each machine working state.
· The power output of each machine remote adjustment.
· Remote viewing offline log of each machine.
· Mail receiving each machine working state.
· The system can set permissions to log on.
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping./100% advance,paypal,WU, etc. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year :5% of total for each years. |
Important Notes for Jamming Distance: The jamming distances we mentioned on website are for customer's reference only. The actual jamming distance will be varied depending on the signal strength and the use location and if full charges, etc.
Important Notes for Portable Jammers with No Cooling Fan: Do not use the jammer when it is charging, or it will burn the jammer as it has no built-in fan. If because of this factor due to the broken of the jammer, the customer will lose the authority of free repairation .
